Research Article, J Spine Neurosurg Vol: 6 Issue: 3

Spinal Cord Stimulation for Pain Relief of Unresectable Sacral Chordoma: Case Report

Draper LM, Towers WS and Kurtom KH^*

Department of Neurosurgery, University of Maryland Community Medical Group, 490 Cadmus Lane, Suite 103, Easton, Maryland, USA

*Corresponding Author : Dr. Khalid H. Kurtom
Clinical Assistant Professor, Department of Neurosurgery, University of Maryland School of Medicine, 490, Cadmus Lane, Suite 103, Easton, Maryland 21601, USA
Tel: 410-820-9117
E-mail: kkurtom@umm.edu

Received: March 06, 2017 Accepted: March 29, 2017 Published: April 08, 2017

Citation: Draper LM, Towers WS, Kurtom KH (2017) Spinal Cord Stimulation for Pain Relief of Unresectable Sacral Chordoma: Case Report. J Spine Neurosurg 6:3. doi: 10.4172/2325-9701.1000267

Abstract

Keywords: SPINE

Case Report

History

An 83-year-old man with a history of an extensive sacral chordoma not amenable to surgical resection presented to the hospital with severe and worsening lower back and lower extremity pain refractory to maximal medical management. He also reported concomitant onset of urinary retention and lower extremity edema. He had a history significant for prostate cancer.

Examination

Exam was notable for a shuffling gait requiring a walker for ambulation. Strength was 5/5 throughout and lower extremity reflexes were 2+ bilaterally.

Imaging included a CT of the bony pelvis, which demonstrated a large sacral chordoma measuring 6.4 cm anterioposteriorly by 9.7 cm transversely by 10 cm sagittally invading the sacral foramen, extending through the right sciatic notch and displacing soft tissue structures within the posterior pelvis (Figure 1). The mass had increased in size by approximately 3 cm in the transverse dimension and to a lesser extent in other dimensions compared to a previous CT completed 12 months prior (Figure 2). Distention of the urinary bladder consistent with urinary retention was also described.

Because maximal conservative management failed to control the patient’s pain, neurosurgery consultation was obtained for an external SCS trial. Application of the stimulator yielded a >50% improvement of symptoms, and the decision was made to place a permanent SCS.

Operation

The inferior spinous process and the inferior lamina of T8, as well as the ligamentum flavum, were resected and a 5-lead paddle electrode from St. Jude was placed on the dorsal aspect of the spinal dura (Figure 3). The patient was awakened intra-operatively and expressed adequate coverage of his lower back and extremity pain. The leads were tacked down to the interspinous ligament and connected to the generator placed in the subcutaneous fat tissue over the left buttock.

Postoperative course

The patient’s postoperative course was unremarkable and he was discharged to home. At his two-week follow-up appointment, he reported significant improvement in his lower back pain and lower extremity symptoms with decreased opioid analgesic requirements. Over the subsequent months, he developed fecal incontinence and elected for a diverting colostomy, as well as worsening urinary retention and lower extremity and scrotal edema. He did not receive palliative chemotherapy or radiation therapy during this time. A oneyear postoperative CT scan revealed an enlarging sacral chordoma measuring 11.3 cm anterioposteriorly by 15.0 cm transversely by 11.8 cm sagittally. However, the patient continued to report adequate pain control from his SCS.

Discussion

The efficacy of SCS has been well established in the treatment of the following conditions: Non-cancer neuropathic pain, including pain from failed back syndrome, ischemic limb pain, angina pectoris, peripheral neuropathies, visceral abdominal pain syndrome, chronic nonalcoholic pancreatitis, abdominal wall neuromas, and posttraumatic splenectomy, refractory to maximal conservative management. However, several studies have also demonstrated SCS efficacy in the treatment of cancer-related pain [1]. One-third of patients with cancer experience pain at the time of diagnosis, and 10- 15% report inadequate pain control with opioid medications alone or in combination with adjuvant analgesics [2-4]. In addition to the impact of intractable pain on quality of life, it often limits treatment compliance and can influence patient survival, demonstrating the importance of identifying effective pain management options for this patient population [3].

Adequate pain management in patients with sacral chordomas is very difficult to achieve. Although wide resection is the preferred management, sacrectomy frequently results in nerve damage and neuropathic pain often refractory to pharmacologic pain management and intrathecal drug delivery [5,6]. Patients with disease not amenable to surgical resection, such as the patient discussed here, also develop neuropathic pain as well as pain from local tissue invasion. A recent systematic review investigating the efficacy of SCS in management of cancer-related pain demonstrated that >80% of participants reported at least a 50% reduction of pain intensity and >50% of participants decreased their usage of opioid medications after implantation of a SCS [1].

The development of SCS was based upon the “gate-control” theory of pain, in which activation of large-diameter afferent fibers via application of an externally applied electric field can “close the gate” to pain transmission [7]. SCS stimulates the dorsal columns, which inhibits transmission through the spinothalamic tract and increases activity in the descending antinociceptive pathways [8,9]. The SCS electrode array may be placed over a spinal cord segment corresponding to the patient’s pain localization, such as over T8-9 for low back and radicular pain, to offer analgesia.

SCS is an appealing novel treatment option for patients with refractory pain from unresectable sacral chordomas. It offers satisfactory symptom relief and an increase in activities of daily living without the associated symptoms of opioid pain medications, such as lethargy or sedation. It is safe and easily reversible without requiring a weaning process and patients are able to control the level of stimulation they require based on their degree of pain [10]. Before a permanent SCS is implanted, a short trial of percutaneously placed temporary epidural leads connected to an external pulse generator is conducted. If pain is reduced by >50%, then the patient is a candidate for permanent SCS placement.

We report a patient with an extensive sacral chordoma not amenable to surgical resection who had failed maximal conservative pain management. Implantation of an SCS yielded a >50% improvement in his lower back and lower extremity pain and led to decreased opioid analgesic use. Despite his continued disease progression, he reported adequate pain control from his SCS months post-implantation. This report contributes further evidence that SCS is a safe and effective treatment option for patients with refractory cancer-related pain including pain from sacral chordomas.

Conclusions

Pain from unresectable sacral chordomas is difficult to manage. It has been well-established that SCS is effective in the treatment of noncancer- related neuropathic pain. This report demonstrates that SCS may also be used to effectively control pain from sacral chordomas refractory to maximal medical therapy.

Conflicts of Interest

We have no conflicts of interest to disclose.

References

1. Peng L, Min S, Zejun Z, Wei K, Bennett MI (2015) Spinal cord stimulation for cancer-related pain in adults. Cochrane Database Syst Rev 1-28.
2. Gralow I (2002) Cancer pain: an update of pharmacological approaches in pain therapy. Curr Opin Anaesthesiol 15: 555-561
3. Ho RC (1994) Pain in the cancer patient. Cancer J Clin 44: 259-261.
4. Sloan P, Melzack R (1999) Long-term patterns of morphine dosage and pain intensity among cancer patients. Hosp J 14: 35-47.
5. Aguilar JL, Espachs P, Roca G, Samper D, Cubells C, et al. (1994) Difficult management of pain following sacrococcygeal chordoma: 13 months of subarachnoid infusion. Pain 59: 317-320.
6. Phimolsarnti R, Waikakul S (2015) Prevalence of neuropathic pain after radical sacral chordoma resection: an observational cohort study with 10-year follow-up. Eur J Orthop Surg Traumatol Orthopédie Traumatol 1: S225-231.
7. Melzack R, Wall PD (1965) Pain mechanisms: a new theory. Science 150: 971-979.
8. Linderoth B, Gazelius B, Franck J, Brodin E (1992) Dorsal column stimulation induces release of serotonin and substance P in the cat dorsal horn. Neurosurgery 31: 289-297.
9. Stiller CO, Linderoth B, O'Connor WT, Franck J, Falkenberg T (1995) Repeated spinal cord stimulation decreases the extracellular level of gamma-aminobutyric acid in the periaqueductal gray matter of freely moving rats. Brain Res 699: 231-241
10. Yakovlev AE, Ellias Y (2008) Spinal cord stimulation as a treatment option for intractable neuropathic cancer pain. Clin Med Res 6: 103-106.
